Recently I wrote an article on how I made 500k with machine learning and HFT (high frequency trading). I submitted the article to Hacker News and it ended up receiving 50,000 unique views. WOW! I thought I had something awesome to share but I had no idea that would happen! It also received 673 likes and 327 tweets. Amazing! By comparison, the actual business I’m launching has received just 135 likes so far - boohoo - though I’m confident that will increase soon.
As a result of the commentary on Hacker News as well as other places around the web I realized there were a lot of important things that I failed to mention in my article. I didn’t really target what I wrote to a trader audience so now I want to take some time to answer the most common questions I received.
Q: Was this really a high frequency trading system?
I would describe my system as a combination of market making, very micro-scale statistical arbitrage, and HFT. It seems that the term HFT is not very clearly defined so let me just tell you a few things about what I was doing and you can decide for yourself:
Q: Isn’t this just a case of survivorship bias?
Quite a few people brought this up. I think it’s great to keep something like this in mind because the fact is many people have tried algorithmic trading and surely most have failed. The difference is they are not writing up a blog post that gets viewed by thousands of people - that’s true.
However, it seemed the implication was that I was simply the guy who got lucky. On this point I strongly disagree. I believe some of the doubt stems from the fact that many people didn’t understand the difference between “running a strategy” versus HFT where you’re picking off consistent profits while exploiting small market inefficiencies. To be fair this is partly my fault for not explaining what I was doing properly
In any case I am extremely confident I was not just getting lucky. There was no directional bias to my system so the fact I traded generally through an up market would not account for my results. My program made long and short trades all throughout the day and did just as well on a down day as an up. Position sizes were always small and as mentioned in the article I made upwards of a thousand trades a day and never lost more than $2000 in one day.
Q: What were the indicators you used?
My article glossed over the indicators my system used for predicting price moves partly because I didn’t think they were the most interesting part of what I did and partly because I didn’t want to get into any math. I thought what was cool was that I built a framework that allowed me to experiment with many indicators and quickly see which indicators had a meaningful ability to predict prices.
However, let me try to give a few more details. I’d say i had two types of indicators. The first type was based on the market microstructure (I think that’s the correct term) of the contract I was trading. So for example - if there is more size on the bid versus the offer an up move was considered more likely. An up move would also be considered more likely if there was recent a trade executed on the offer.
The other type of indicator involved looking at markets that were correlated with what I was trading and making predictions based on what was happening in them (ie arbitrage). So essentially if the S&P moved up it’s likely the Russell would move up as well. Most of these indicators were valid at very small time scale (ie milliseconds).
The indicators were indeed more sophisticated than what I describe here but hopefully you get the idea. Also, keep in mind predicting prices was only part of the story - I also relied on market making tricks such as keeping bids in the market if other orders were queued up behind mine but canceling them if not. As mentioned in the article my success required finding “safe” places to bid and offer.
The original article can be viewed here.
This post will detail what I did to make approx. 500k from high frequency trading from 2009 to 2010. Since I was trading completely independently and am no longer running my program I’m happy to tell all. My trading was mostly in Russel 2000 and DAX futures contracts.
The key to my success, I believe, was not in a sophisticated financial equation but rather in the overall algorithm design which tied together many simple components and used machine learning to optimize for maximum profitability. You won’t need to know any sophisticated terminology here because when I setup my program it was all based on intuition. (Andrew Ng’s amazing machine learning course was not yet available - btw if you click that link you’ll be taken to my current project: CourseTalk, a review site for MOOCs)
First, I just want to demonstrate that my success was not simply the result of luck. My program made 1000-4000 trades per day (half long, half short) and never got into positions of more than a few contracts at a time. This meant the random luck from any one particular trade averaged out pretty fast. The result was I never lost more than $2000 in one day and never had a losing month:
(EDIT: These figures are after paying commissions)
And here’s a chart to give you a sense of the daily variation. Note this excludes the last 7 months because - as the figures stopped going up - I lost my motivation to enter them.
My trading background
Prior to setting up my automated trading program I’d had 2 years experience as a “manual” day trader. This was back in 2001 - it was the early days of electronic trading and there were opportunities for “scalpers” to make good money. I can only describe what I was doing as akin to playing a video game / gambling with a supposed edge. Being successful meant being fast, being disciplined, and having a good intuitive pattern recognition abilities. I was able to make around $250k, pay off my student loans and have money left over. Win!
Over the next five years I would launch two startups, picking up some programming skills along the way. It wouldn’t be until late 2008 that I would get back into trading. With money running low from the sale of my first startup, trading offered hopes of some quick cash while I figured out my next move.
A trading API
In 2008 I was “manually” day trading futures using software called T4. I’d been wanting some customized order entry hotkeys, so after discovering T4 had an API, I took on the challenge of learning C# (the programming language required to use the API) and went ahead and built myself some hotkeys.
After getting my feet wet with the API I soon had bigger aspirations: I wanted to teach the computer to trade for me. The API provided both a stream of market data and an easy way to send orders to the exchange - all I had to do was create the logic in the middle.
Below is a screenshot of a T4 trading window. What was cool is that when I got my program working I was able to watch the computer trade on this exact same interface. Watching real orders popping in and out (by themselves with my real money) was both thrilling and scary.
The design of my algorithm
From the outset my goal was to setup a system such that I could be reasonably confident I’d make money before ever making any live trades. To accomplish this I needed to build a trading simulation framework that would - as accurately as possible - simulate live trading.
While trading in live mode required processing market updates streamed through the API, simulation mode required reading market updates from a data file. To collect this data I setup the first version of my program to simply connect to the API and record market updates with timestamps. I ended up using 4 weeks worth of recent market data to train and test my system on.
With a basic framework in place I still had the task of figuring out how to make a profitable trading system. As it turns out my algorithm would break down into two distinct components, which I’ll explore in turn:
Predicting price movements
Perhaps an obvious component of any trading system is being able to predict where prices will move. And mine was no exception. I defined the current price as the average of the inside bid and inside offer and I set the goal of predicting where the price would be in the next 10 seconds. My algorithm would need to come up with this prediction moment-by-moment throughout the trading day.
Creating & optimizing indicators
I created a handful of indicators that proved to have a meaningful ability to predict short term price movements. Each indicator produced a number that was either positive or negative. An indicator was useful if more often than not a positive number corresponded with the market going up and a negative number corresponded with the market going down.
My system allowed me to quickly determine how much predictive ability any indicator had so I was able to experiment with a lot of different indicators to see what worked. Many of the indicators had variables in the formulas that produced them and I was able to find the optimal values for those variables by doing side by side comparisons of results achieved with varying values.
The indicators that were most useful were all relatively simple and were based on recent events in the market I was trading as well as the markets of correlated securities.
Making exact price move predictions
Having indicators that simply predicted an up or down price movement wasn’t enough. I needed to know exactly how much price movement was predicted by each possible value of each indicator. I needed a formula that would convert an indicator value to a price prediction.
To accomplish this I tracked predicted price moves in 50 buckets that depended on the range that the indicator value fell in. This produced unique predictions for each bucket that I was then able to graph in Excel. As you can see the expected price change increases as the indicator value increases.
Based on a graph such as this I was able to make a formula to fit the curve. In the beginning I did this “curve fitting” manually but I soon wrote up some code to automate this process.
Note that not all the indicator curves had the same shape. Also note the buckets were logarithmically distributed so as to spread the data points out evenly. Finally note that negative indicator values (and their corresponding downward price predictions) were flipped and combined with the positive values. (My algorithm treated up and down exactly the same.)
Combining indicators for a single prediction
An important thing to consider was that each indicator was not entirely independent. I couldn’t simply just add up all the predictions that each indicator made individually. The key was to figure out the additional predictive value that each indicator had beyond what was already predicted. This wasn’t to hard to implement but it did mean that if I was “curve fitting” multiple indicators at the same time I had to be careful; changing one would effect the predictions of another.
In order to “curve fit” all of the indicators at the same time I setup the optimizer to step only 30% of the way towards the new prediction curves with each pass. With this 30% jump I found that the prediction curves would stabilize within a few passes.
With each indicator now giving us it’s additional price prediction I could simply add them up to produce a single prediction of where the market would be in 10 seconds.
Why predicting prices is not enough
You might think that with this edge on the market I was golden. But you need to keep in mind that the market is made up of bids and offers - it’s not just one market price. Success in high frequency trading comes down to getting good prices and it’s not that easy.
The following factors make creating a profitable system difficult:
Building a full trading simulation
So I had a framework that allowed me to backtest and optimize indicators. But I had to go beyond this - I needed a framework that would allow me to backtest and optimize a full trading system; one where I was sending orders and getting in positions. In this case I’d be optimizing for total P&L and to some extent average P&L per trade.
This would be trickier and in some ways impossible to model exactly but I did as best as I could. Here are some of the issues I had to deal with:
To refine my order execution simulation what I did was take my log files from live trading through the API and compare them to log files produced by simulated trading from the exact same time period. I was able to get my simulation to the point that it was pretty accurate and for the parts that were impossible to model exactly I made sure to at least produce outcomes that were statistically similar (in the metrics I thought were important).
Making profitable trades
With an order simulation model in place I could now send orders in simulation mode and see a simulated P&L. But how would my system know when and where to buy and sell?
The price move predictions were a starting point but not the whole story. What I did was create a scoring system for each of 5 price levels on the bid and offer. These included one level above the inside bid (for a buy order) and one level below the inside offer (for a sell order).
If the score at any given price level was above a certain threshold that would mean my system should have an active bid/offer there - below the threshold then any active orders should be cancelled. Based on this it was not uncommon that my system would flash a bid in the market then immediately cancel it. (Although I tried to minimize this as it’s annoying as heck to anyone looking at the screen with human eyes - including me.)
The price level scores were calculated based on the following factors:
Essentially these factors served to identify “safe” places to bid/offer. The price move prediction alone was not adequate because it did not account for the fact that when placing a bid I was not automatically filled - I only got filled if someone sold to me there. The reality was that the mere fact of someone selling to me at a certain price changed the statistical odds of the trade.
The variables used in this step were all subject to optimization. This was done in the exact same way as I optimized variables in the price move indicators except in this case I was optimizing for bottom line P&L.
What my program ignored
When trading as humans we often have powerful emotions and biases that can lead to less than optimal decisions. Clearly I did not want to codify these biases. Here are some factors my system ignored:
Since my algorithm made decisions the same way regardless of where it entered a trade or if it was currently long or short it did occasionally sit in (and take) some large losing trades (in addition to some large winning trades). But, you shouldn’t think there wasn’t any risk management.
To manage risk I enforced a maximum position size of 2 contracts at a time, occasionally bumped up on high volume days. I also had a maximum daily loss limit to safeguard against any unexpected market conditions or a bug in my software. These limits were enforced in my code but also in the backend through my broker. As it happened I never encountered any significant problems.
Running the algorithm
From the moment I started working on my program it took me about 6 months before i got it to the point of profitability and begun running it live. Although to be fair a significant amount of time was learning a new programming language. As I worked to improve the program I saw increased profits for each of the next four months.
Each week I would retrain my system based on the previous 4 weeks worth of data. I found this struck the right balance between capturing recent market behavioral trends and insuring my algorithm had enough data to establish meaningful patterns. As the training began taking more and more time I split it out so that it could be performed by 8 virtual machines using amazon EC2. The results were then coalesced on my local machine.
The high point of my trading was October 2009 when I made almost 100k. After this I continued to spend the next four months trying to improve my program despite decreased profit each month. Unfortunately by this point I guess I’d implemented all my best ideas because nothing I tried seemed to help much.
With the frustration of not being able to make improvements and not having a sense of growth I began thinking about a new direction. I emailed 6 different high frequency trading firms to see if they’d be interested in purchasing my software and hiring me to work for them. Nobody replied. I had some new startup ideas I wanted to work on so I never followed up.
UPDATE - I posted this on Hacker News and it has gotten a lot of attention. I just want to say that I do not advocate anyone trying to do something like this themselves now. You would need a team of really smart people with a range of experiences to have any hope of competing. Even when I was doing this I believe it was very rare for individuals to achieve success (though I had heard of others.)
There is a comment at the top of the page that mentions ”manipulated statistics” and refers to me as a “retail investor” that quants would “gleefully pick off”. This is a rather unfortunate comment that’s simply not based in reality. Setting that aside there’s some interesting comments: http://news.ycombinator.com/item?id=4748624
UPDATE #2 - I’ve posted a follow-up FAQ that answers some common questions I’ve received from traders about this post.
